• The elevation of the antenna can be adjusted and locked manually, the adjustment range is -3º～15º
• The azimuth of the antenna can be adjusted and locked manually, the adjustment range is ± 15º
• The antenna is provided with horizontal bubble device ,which can show whether the antenna is horizontal
• EL range: -3º～15º (in 1º accuracy)
• AZ range: ±15º (in 1º accuracy)
• PL range: 0º,± 90º (supported positions)
• The antenna is provided with position for fixing the rope, the rope length can be adjusted and the locking device is provided
• The center height of antenna reflector: ≥ 2m the maximum height is ≤ 2.5m
• Assembly time ≤ 5min (2 persons)
